PVC door system
Door profile for an innovative 7-chamber premium-class. PVC system with enhanced comfort levels (Smart Comfort), surpassing conventional energy efficiency standards. It combines timeless design, excellent quality, and high-level reliability.
Number of chambers
7
Installation depth
80 mm
Seal
3 contours, TPE
Filling thickness
42 mm, 50 mm
| Installation depth | 80 mm |
| Visible profile height (frame + sash) | 153 mm |
| Threshold height | 20 mm |
| Fill thickness | 42 mm, 50mm |
| number of profile chambers (frame/sash) | 7/4 |
| Sealing system | 3 contours, TPE |
| Profile thermal transmittance coefficient (Uf) | 1,1 W/m²K |
| коефіцієнт опору теплопередачі профілю (Rf) | 0,91 m²°С/W |
| max sash size | 1400х3000 mm |
| max frame size | 3000х3000 mm |
| min frame size | 400х400 mm |
| Width of the main chamber | 41,8 mm |
| Glass beads | at an 90° angle |
| Surface | Glossy |
| Hardware | Axis 13 mm |
| Burglary protection | RC2 |
Framex 80 PVC profiles are made from PVC-U in accordance with DSTU B V27-130 requirements The thickness of the profile walls meets class B according to DIN EN 12608 / class B according to DSTU B V27-130.
The Framex 80 system offers new opportunities for private and commercial construction.
The profile design provides high thermal resistance values. A filling depth of up to 50 mm allows for the use of wide insulating glass units in doors, offering high thermal and acoustic insulation properties.
The modern design of the glazing bead profile with an external angle of 90° gives door structures a stylish appearance. Three sealing contours provide maximum thermal insulation properties and enhance the soundproofing and water resistance of the doors.
Strength
The use of stronger reinforcement ensures high stability of the structure
Sleek design, similar to aluminum
The sash is in the same plane as the frame, with narrow joints and a new system of glass beads with rectangular edges
The color of the profile can be standard white or colored.
PVC is laminated on both sides – at the request of the customer in the desired lamination color.
Tall, stable, and rigid sashes without the risk of sagging
Glass beads 90°
Rigid reinforcement
Withstands high wind and thermal loads The system maintains stability even with heavy glazing
80 mm – Installation depth
3 Seal contour
7-Multi-chambered profile system
Minimal heat loss and low heating costs in winter
Controlled ventilation of the cavity between the profile groove and the edge of the insulating glass unit is achieved through drainage and ventilation holes located in the outer chambers of the frames and sashes, ensuring effective drainage of condensation and rainwater. The profile design allows moisture to be directed sideways or downwards using specialized drainage profiles.
The leveling grooves of the linings ensure high-quality and fast glazing Supporting profiles and expanders feature enhanced thermal resistance due to increased chamber quantity and additional seals along the groove.
The additional profiles included in the system allow for various options for connecting structures to each other, as well as increasing the width of the frame profiles, which is necessary for strip glazing of facades and spatial glazing of pavilions. The frame profile legs allow for tight connection of a large number of additional profiles, as well as flexible anchor plates for wall mounting.
The width of the reinforcement chambers in the profiles allows for the use of reinforcement profiles with high static characteristics. The reinforcement profiles for the frame, window sash, 50 mm height extender, and supporting profile are identical, which is an important advantage for processors. The profile system allows for the use of standard hardware from various manufacturers, both in regular and anti-burglary configurations.
